High performance. Fully adaptable.

The Master Multi Pro S WT is a 5-axis CNC bridge saw designed for multi-processing of slabs and large blocks. Its robust structure and advanced 5‑axis head enable straight, inclined, curved, and 3D shaping operations. Highly configurable in layout and options, it adapts to any production need with precision, reliability, and performance.

Human Machine Interface

Control at your fingertips: smart, intuitive and ready to go. The 21″ ergonomic multitouch HMI is integrated into the machine controls, supported by GMM software designed to be simple, innovative and intuitive, enabling quick and efficient start-up of any stone-processing job.

Highly Configurable and Adaptable

Thhis machine is fully configurable to meet any production requirement. Its modular design supports multiple work tables, automatic unloading, tool magazines, or even a lathe, while maintaining workflow efficiency and safety. Ideal for homeware, interior design, architectural elements, funerary art, or large-scale stone blocks, it adapts to every project, from slab cutting to massive 2-meter blocks.

Two Versions

The machine is available in two versions to meet different production needs. The L version is ideal for standard slabs and medium-thickness blocks, while the Z version handles large blocks and complex 3D components with ease. Both deliver precision, efficiency, and full adaptability, with modular layouts and optional features to fit any workflow.

5 Axis Technology

Unlock complex cuts with ease. The 5-axis bridge saw enables advanced stone processing with precision. Its head moves and rotates in multiple directions, allowing complex shapes and angles to be cut efficiently, all while maintaining stability and accuracy.

Automatic Tool Changer

Smooth transitions for nonstop productivity. The automatic tool magazine, available with 12 or 24 ISO40/ISO50 positions, enables fast tool changes and keeps machining workflows efficient, even when handling large or heavy tooling setups.

Lathes

Precision shaping made simple. Lathes rotate the workpiece for accurate turning operations, allowing smooth and controlled material shaping. They support a wide range of configurations, making them versatile tools for diverse machining needs.

Z strokes

This machine offers configurable Z-axis strokes of 1000, 1300, 1600, and 2000 mm. Combined with adjustable or multiple worktable heights, this flexibility allows machining of a wide range of material thicknesses, adapting to every production need.

Built for Tough Conditions

The machine’s architecture features solid cast-iron and hot-dip galvanized steel components, ensuring strength and long-term stability. Its construction resists water, dust, and abrasive stone particles, making it ideal for wet cutting, marble, granite, and demanding workshop conditions.

Main Technical Data

TECHNICAL DATA	U.M.	Value Version L	Value Version Z
Interpolated Axes	n°	5	5
Maximum longitudinal stroke (X Axis)	[mm]	3850	3900
Bridge translation (Y Axis) (Min/Max Std defined)	[mm]	2940 to 9500	3650 to 14450
Maximum vertical travel of the blade (Z Axis)	[mm]	1000	1300 / 1600 / 2000
Maximum Blade Orientation Angle (W Axis)	°	0 ÷ 370	0 ÷ 370
Maximum blade tilting (R Axis)	°	-15°÷+105° / 0°÷+90°	-15°÷+105° / 0°÷+90°
Worktable Area	[mm]	3500x2000	3500x2000
Worktable Area with table extension	[mm]	3500x2460	3500x2460
Maximum blade diameter std /Optional	[mm]	925 / 1100 - 1300	925 / 625- 1100 - 1300
Maximum cutting depth	[mm]	280 / 512	280 / 512
Blade Hole? for Std Motor / Blade hole fo Iso 50 Cone	[mm]	60 / 95	60 / 95
Blade Locking Flange Diameter	[mm]	253.5/266	253.5/266
Blade motor power std / Iso 50 Cone	[kW]	33.3 (S6) / 40 (S6) water cooling	33.3 (S6) / 40 (S6) water cooling
Variable Blade Speed? for Std Motor / for Iso cone 50 Motor	[rpm]	950 ÷ 1460 / max 8000	950 ÷ 1460 / max 8000
Variable Sledge Cutting Speed (X Axis)	[m/min]	37	37
Variable Sledge Cutting Speed (Y Axis)	[m/min]	37	37
Maximum Speed Z Axis	[m/min]	8,5	6
Water Clean Consumption (3 bar - psi)	[l/min]	15	15
Air Consumption (6 Bar - psi) (* With Vacuum System) / **ISO CONE 50	[l/min]	25 (300) / (200-550*)	25 (300) / (200-550*)
Max liftable weight with vacuum system	[kg]	500	500
Standard Installation Dimensions (Width X Depth X Height)	[mm]	8190x5520x4850	8470x7960x4690
Total machine mass (without steel wall and table)	[kg]	5580	8050
